Spectra LL500 Laser Level
The Spectra Precision® LL500 Laser Level is a one-person leveling system designed for longer range measurements across your entire site. Accurate, stable and reliable, the LL500 Laser Level features a 1,600 ft (500 m) working diameter which increases productivity by reducing the need for multiple setups on a large job site. The rugged LL500 is self-leveling with built-in ""out-of-level" shutoff that maintains accuracy over the entire work area and minimizes errors. Visible "spotting" beam determines receiver mounting placement makes it faster to find the on-grade position. Features & Benefits:- High accuracy with temperature compensation provides highly stable, repeatable accuracy even under large temperature changes.
- Alkaline or rechargeable batteries keep the unit working and minimize downtime due to power loss.
- Self-leveling with built-in shut off for increased accuracy over the entire work area and reduced errors.
- Comes with choice of HL700 or CR600 receivers so you can choose the best option to suit your application.
- Reduces the amount of time required for each grade shot, so more grade shots are taken for increased accuracy.
- Eliminates rework caused by miscommunication or out-of-level instruments with built-in out-oflevel warning and shut-off.
- Immediately locates the laser plane with the visible spotting beam.
- Self-Leveling Range: ± 11 arc minutes
- Compensation Type: Wire Hung, Air Damped
- Accuracy: 1.5 mm at 30 m (1/16 in at 100 ft) ±10 arc seconds
- Temperature Compensation: Yes
- Laser Type: 670 nm visible
- Class II Machine Control Compatible: Yes
- Battery Life 20°C (68°F): 4 D-Cell Alkaline - 175 hrs NiMH - 100 hrs, NiCad - 75 hrs
- Operating Diameter: 500 m (1,600 ft)
- Operating Temperature: -20°C to 50°C (-4°F to 122°F)
- Weight: 3.6 kg (8 lbs)
- Tripod Mount: 5/8 in x 11
- Warranty: 5 Years
Package Includes:
- LL500 Laser Level
- Alkaline Batteries
- Carrying Case
- Receiver
